OVERVIEW

Output torque

T2N : 75 Nm – 5905 Nm

Ratios:

2-stage : 4 / 5.5 / 8 / 11 / 16 / 20 / 22 / 27.5 / 28 / 38.5 / 40 / 55

3-stage : 64 / 88 / 100 / 110 / 137.5 / 140 / 154 / 160 / 200 / 220 / 280 / 385

4-stage : 400 / 440 / 500 / 550 / 700 / 770 / 1000 / 1078 / 1400 / 1540 / 1600 / 2000 / 2695 / 2800 / 3850 / 4000 / 5500

Low backlash

2-stage :≤ 4 arcmin

3-stage :≤ 4 arcmin

4-stage :≤ 4 arcmin

High efficiency

2-stage :≧ 94 ~ 95 %

3-stage :≧ 92 %

4-stage :≧ 90 %

Standard Flange or Curvic Output

SIZE

MGHCK115 / MGHCK140 / MGHCK170 / MGHCK240 /

MGHCK285 / MGHCK320
