-PCD of Screw Holes or DIN 5480 Teeth No. or Internal Diameter

-Sub-Series according to Fig.

A = Fig. A

B = Fig. B

C = Fig. C

-Pinion Teeth No.

-Teeth Angle

L = Left-Hand Helical 19°31’42”

l* = Straight

-Module-No.

1∼12

The non-integer module no. will be given in alphabet.

-Series

A =Curvic Plate

B =Welded Plate

C= Teeth Plate

D= DIN 5480

E, F = Keyway

G = Long Shaft w. KW

H = Long Shaft w/o KW



COMMON CODE:

Set	Pinion only
A02L17B031	A02L17
A02L20B050	A02L20
A02L20A063	A02L20
A02L20C063	A02L20
A03L18A080	A03L18
A03L18C080	A03L18
A08L15A200	A08L15
