KL9010 | End terminal

The KL9010 bus end terminal is necessary for data exchange between the Bus Coupler and the Bus Terminals. Each assembly must be terminated at the right hand end with a KL9010 bus end terminal. The bus end terminal does not have any other function or connection facility.

K-bus, looped through –/yes

Bit width in the process image 0

Electrical connection to DIN rail –

Housing width 12 mm

Special features end terminal for bus communication

Weight approx. 50 g

Side by side mounting on Bus Terminals with power contact yes

Side by side mounting on Bus Terminals without power contact yes

Operating/storage temperature -25…+60 °C/-40…+85 °C

Approvals/markings CE, UL, ATEX, IECEx, DNV GL, cFMus

Ex marking ATEX:

II 3 G Ex nA IIC T4 Gc

IECEx:

Ex ec IIC T4 Gc

cFMus:

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx ec IIC T4 Gc
