Product Description

Simple function

Simple installation, low cost

Protection height from 185mm – 1,105mm

20mm beam distance, 870 nm . infrared LED light source

Installation distance from 0.2m – 7m

Built-in cable, PNP (Open Collector) output

Fast response time 15ms

Power supply 24 VDC±20%

Qualified:

– IEC 61496-1, EN 61496-1 UL 61496-1, Type 4 ESPE (Electro-Sensitive Protective Equipment)

– IEC 61496-2, CLC/TS 61496-2, UL 61496-2, Type 4 AOPD (Active Opto-electronic Protective Devices)

– IEC 61508-1 to -3, EN 61508-1 to -3 SIL3

– IEC 13849-1:2006, EN ISO 13849-1:2008 (PLe, Cat.4)

– UL 508, UL 1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8
